Wireless outdoor multimedia system


Mbox is a multimedia speaker specially designed for outdoor entertainment. It is hard-looking and widely used. It is not only Bluetooth speaker, but also equipped with portable wireless microphone. It can perfectly meet the needs of outdoor singing and outdoor speech scene. At the same time, Mbox with projector and song clicker is a complete outdoor audio-visual system. Not only can you enjoy professional outdoor video KTV, but also can feel the shock of outdoor stereo cinema. It is the best entertainment partner for outdoor parties, large camps and outdoor clubs.

  • Description
  • Specifications
  • Download

MBox Speaker

• 60W high power, HiFi texture, shock bass.

• Wireless Interconnected Broadcasting Sharing Mode

• 40 m effective range

• 5.8G wireless microphone, can give a speech or sing a song

• Disassembled high-capacity battery (22H range), fast second-level switching

• Bluetooth, stereo, electric guitar, wireless microphone, SD card and other input modes

• X-type skeleton embracing, fall proof and shock proof

• IP65 Class Dust-proof and Waterproof

• Vertical speaker bracket for outdoor audio and video


Mmic 5.8G Wireless handheld microphone

• 5.8G wireless transmission technology

• 20 m effective distance

• Reverberation voice technology, human voice magnetic

• enhancement technology

• Dust-proof and waterproof design


WM58 5.8G wireless receiver

• 5.8G wireless transmission technology.

• 20 m effective distance

• Small size, without affecting the appearance of the speaker

MBox

Power: 60W（RMS）

S/N: 92dB

T.H.D.: ≤0.05%

Sound Resolution: 24bit/48KHZ

Audio Freq Range: 30HZ-18KH2

Input Power: 24V/3A

Output Power: 16V-24V/3A'2(in storage box, for projector and VOD power connection)

Speaker Unit: 8” woofer+225” full range speaker(stereo)+ 2'passive speakers

Input: 6. 35mm stereo input socket (in storage cabin, for functions extending), SD card, wireless microphone. 6.35mm electronic guitar socket, 3.5mm stereo input socket

Working Time: 7-10H

Charging Time: 6-8H

Battery Capacity: 7.8AH'18.5V

Bluetooth Version: 4.2, compatible for 2.1

Sensitivity: 87DB SPL/Wm

Water Proof Grade: IP65 dust proof and water proof

Working Temperature: 0'c-50'C(battery pack for normal temperature 15'c-50c(battery pack for ultra low temperature)

Dimensions: 280(W)*442(H)*295(L)mm

Weight: 10.4kg


Mmic

Radio Frequency Carrier Range: 5740-5820 MHz

Working Distance: open space > 20M

Frequency Response: 20HZ ~ 20KHZ (+3dB)

Dynamic Range: > 90dB

T.H.D.: <0.05%

S/N: > 92 dB (A)

Radio Frequency Receiving Sensitivity: <-81 dBm

Transmitting Power: > 7 dBm

System Delay: <8ms

Digital Audio: 24-bit, 48KHz sampling rate

Power Requirements: 3.7V rechargeable lithium bat

Working Current: <135mA

Battery Life: 6H

Battery Charging Time: < 3H

Dimensions : 210(L) * 49(Φ)mm

Weight: 195g


WM58

Radio Frequency Carrier Range: 5740-5820 MHz

Working Distance: open space > 20M

Frequency Response: 20HZ ~ 20KHZ (+3dB)

Dynamic Range: > 90dB

T.H.D.: <0.05%

S/N: > 92 dB(A)

Radio Frequency Receiving Sensitivity: <-81 dBm

Transmitting Power: > 7 dBm

System Delay: <8ms

Digital Audio: 24-bit, 48KHz sampling rate

Receive Power Supply: USB 5V

Working Current: <80mA

Dimensions : 77(L) * 29(W)* 13(H)mm

Weight: 17g
