PAW-900 Single Channel True Diversity Wireless Microphone System


The PAW-900 wireless microphone system consists of the PAW-900 receiver, the PAH-801 handheld transmitter or the PBT-801 bodypack transmitter. The system has 10 frequency groups with a total of 160 channels, and each frequency band has up to 16 channels that do not interfere with each other. The system has the functions of automatically searching for idle channels, infrared data synchronization and the like. The system offers a rock-solid performance,crystal clear sound quality,intuitive operation.An ideal choice for professional clubs,churches and other demanding venuse.

  • Description
  • Specifications
  • Download
• True diversity design ensures rock-solid performance
• LCD shows all working status.
•  Up to 192 selectable frequencies
•Automatic frequency selection
•Adjustable gain level
• 6-segment audio meters
• 6-segment RF meters
•3-segment transmitter battery fuel gauges
•Squelch adjustment                                                                   •Infrared data synchronlzauon
•Rugged metal chassis
•Modularized microphone head design of handheld transmitter for free choice and easy replacement
•LCD screen with orange backlight indicates frequency, battery life, RF, gain,mute and Lock status
•3 optional audio gain adjustments
•3 optional transmit power adjustments
•Infrared data synchronization
•Rock-solid metal body design and strong rubber end structure with good anti-droperformance		•LCD screen with orange backlight indicates frequency, battery life, RF, gain,mute and Lock status
•3 optional audio gain adjustments
•3 optional transmit power adjustments
•Infrared data synchronization


RF Carrier Frequency Range: 500 ~ 937.5MHZ
Modulation : FM
Working  Range: 100M
Modulation: FM
Pilot Tone: 32.768KHZ
Max Channel Number: 192
System Compatibility: 8pcs systems can operate simutaneously
Audio Frequency Range: 50HZ ~ 15KHZ (±3db)
Dynamic Range: > 105db
System Distortion:T.H.D< 0.5%
S/N Ratio: > 102db (A)
RF Sensitivity: < -95dbm for 30db S/N Ratio
Image Rejection: > 60db
Output Connectors: (XLR×1)/(1/4-inch connector×1)
Audio Output Level:  (XLR: +10dbV) / (1/4-inch connector: +8dbV)
Impedance: (XLR: 3KΩ)/(1/4-inch connector: 3KΩ)
Display:  LCD×1
Power Requirements:  12V/0.5A DC
Operating Temperature Range: 0-50 ℃
 Dimensions:160*212*44
Weight: 880g

Gain Adjustment Range: 0/3/6db
Impedance: 5KΩ
RF Power Output: 2mW/10mW/30mW
Spurious Rejection: > 50db
Pilot Tone: 32.768KHZ
Display: LCD
Power Requirements: 1.5V*2(AA)
Battery Life: >8h/1300mAH
Dimensions:250*50mm
Weight: 360g		Gain Adjustment Range: 0/3/6db
Input Impedance: 5KΩ
RF Power Output: 2mW/10mW/30mW
Harmonic Rejection: > 50db
Pilot Tone: 32.768KHZ
Display: LCD
Power Requirements: 1.5V*2(AA)
Battery Life: >8h/1300mAH
Dimensions:65*165*23mm
Weight: 130g
